M.Zuiko ED 100-400mm F5.0-6.3 IS at a Glance

A compact lens with so much telephoto reach shouldn’t be possible. Yet here it exists, and you’ll love the freedom that comes with it. Packing a 35mm-equivalent focal range of 200mm to 800mm in a lightweight weathersealed design, it’s an ideal lens for wildlife, motorsports, and telephoto macro shooting.

200-800mm Focal Length (35mm equivalent)
Zero Coating
AF / MF Switch
1.4x Teleconverter Compatible
Bright 5.0 Aperture
MSC Movie & Still Compatible

Splashproof, Dustproof
2.0x Teleconverter Compatible
.57x Max Image Magnification
Super HR Glass
In-Lens Image Stabilization
AF Limiter

F5.0

Bright 5.0 Aperture

200-800mm

35MM Equivalent Focal Length

0.17x - 0.57x

35mm Equivalent Max. Image Magnification

For on-the-go

M.Zuiko everyday lenses offer a solution for every shooting situation, whether you need a convenient low-profile lens or a high-powered zoom.

Reach Farther

The M.Zuiko 100-400mm IS lets you get incredibly close from wherever you are. A perfect tele-macro choice, with a wide working distance.

Weathersealed

The entire lens barrel is hermetically sealed to keep moisture, dust, and debris out. Stop worrying about the weather conditions around you and focus on getting your shot.

Handheld Sharpness

Easily go to the locations with the best shots. The M.Zuiko 100-400mm IS’ built-in image stabilization frees you to shoot handheld.

Technical specifications

Open full list of technical specifications

M.Zuiko Digital ED 100-400mm F5.0-6.3 IS OM technical specifications

Lens Construction
- Lens configuration 21 elements / 15 groups
- Maximum image magnification 0.09x (wide) / 0.29x (tele)
- (equiv. 35mm) 0.17 x (wide) / 0.57 x (tele)
- Angle of view 12 - 3.1°
- Focusing method High-speed Imager AF (MSC)
- Closest focusing distance 1.3m
- Minimum field size 202.4 x 152.1mm (wide)
  60.3 x 45.3mm (tele)
- ED lens elements 4
- HR elements 2
- Super HR elements 2
Focal Length
- Focal length 100 - 400mm
- Focal length (equiv. 35mm) 200 - 800mm
Aperture
- Maximum aperture F5.0 (wide) / F6.3 (tele)
- Minimum aperture F22
- Number of aperture blades 9 Circular aperture diaphragm for natural background blurring
Image Stabiliser
- Effective Compensation Range Up to 3 EV steps Not compatible with Sync IS
Pro Features
- Dust, splash & freezeproof Available
Lens Combinations
- M.Zuiko Digital ED 40-150mm F2.8 PRO
- M.Zuiko Digital ED 100-400mm F5.0-6.3 IS
- M.Zuiko Digital ED 300mm F4 IS PRO
Converter Combinations
- Maximum image magnification
- MC-14
- Maximum image magnification 0.12 x (wide) / 0.40 x (tele)
- (equiv. 35mm) 0.24 x / 0.81 x (equiv. 35mm)
- Minimum field size 143.5 x 107.9mm (wide)
  42.8 x 32.1mm (tele)
- Effective Compensation Range Up to 2 EV steps* (Lens IS)
- Note * According to CIPA standards. With yaw and pitch applied and focal length set to 560mm.
- MC-20
- Maximum image magnification 0.17 x (wide) / 0.57 x (tele)
  0.34 x / 1.15x (equiv. 35mm)
- Minimum field size 101.2 x 76.0mm (wide)
  30.1 x 22.6mm (tele)
- Effective Compensation Range Up to 1.5 EV steps* (Lens IS)
- Note * According to CIPA standards. With yaw and pitch applied and focal length set to 800mm.
Dimensions / Weight
- Diameter 86.4mm (greatest dimension)
- Length 205.7mm
- Filter diamater 72mm
- Weight 1.120g
Compatibility
- Compatible to Tele Converter MC-14 Yes
- Compatible to Tele Converter MC-20 Yes
- Operates with 5-axis Sync IS No
